NOTE:

1. OBD model can not support some car, pls contact with us before buy

2. GPS Model for All car

3.pls let us know your email  if need Car List

P10 T600 Hud GPS OBD Computer Car Speed Projector Digital Speedometer Display Fuel Consumption Temperature Gauge Diagnostic Tool

P10

OBD smart digital device is equipped with a very powerful detection for error code, the device can display the error code information clearly in text form,and it can clear the fault information,and display accelerating competitive mode,brake performance test mode, read the entire vehicle data stream information,and the other functions.

Main Functions&Features:

1.Available for cars with OBD2 and EUOBD port(Car automatic diagnosis system) ,plug and play

2.TFT LCD multi color smart display

3.The first scan will show the vehicle protocol

4.The language can be changed

5.Multi function display mode or simple function display mode can be switched freely

6.Add new functions: accelerating competitive mode ,Brake performance test, can read the entire car data stream information

7. Rich Contents:vehicle speed,engine RPM,water temperature,voltage,instantaneous fuel consumption,average fuel consumption,driving distance measurement,driving time ,low voltage alarm,high water temperature alarm,over speed alarm, engine fault code alarm, eliminate the fault code,freely switch between kilometers&miles.

Technical Parameters:

Environment temperature: -40c- + 80c

atmospheric pressure 86-106KPa

Relative Humidity: 10% -95%

environmental noise <= 60dB (A)

Alarm sound level: 》=30dB (A)

Working voltage: 9V ~ 16Vdc (12Vdc / 400mA)

Product size: 73*68*46(cm)

Product Weight: 50 g

Troubleshooting

1.The screen without any display,and no power

Start the car engine;check if the OBD cable line is tight;please pull down the OBD cables more times to ensure;check if product power switch turns on. If still no display ,please change another car to test, analyze whether the car OBD diagnostic interface is good, if it is not good,please repair it and try again.

2.Only shows the car voltage and be automatic power off after 60 second when the device is with power

this product just available for cars with OBD2 agreement and EU-OBD agreement（European region: after 03 years, Other region:after 07 years）

This Products donnot support JOBD and OBDI and recommended test for another car.

3.Inaccurate Speed

a.First check the speed unit is correct or not, the speed unit including KM/H and MPH,please refer to the setting to switch the unit.

b.When the product is power on,long press in the button to enter into the menu option,and right push once switch to setting,then short press in the button to the menu,and right push the button switch to the speed adjust option.(if the dashboard shows 100,and the device shows the 101,change the default value at 106%)

4.Inaccurate Fuel consumption

Check your car displacement,and set the device same as your car(if your car is 2.0L,then change the device value at 2.0L).The fuel consumption can be adjusted,but we don’t suggest to change it ,because all the datas are read from the car ECU directly.

5.RPM Alarm

Default alarm is 6000,please refer to the setting to change.

6.Over peed alarm

Default alarm is 150KM/H,please refer to the setting to change the value.

7.The device cannot auto power off

A.After vehicle turns off,the device still display the speed,switch the setting to Speed Offset,and adjust the value same as the device speed.(if the device shows 5KM/H after the vehicle turns off,then change the speed offset at 5KM/H)

B.After vehicel turns off,the device still display the RPM,switch the setting to sleep voltage,and make the value at 13.2V

8. Auto start and stop cars

Change the Power off time to 180s

9.Wrong operation lead to crashes

Do a factory set

10. Why it will cause the car dashboard fault code bright?

As Universal OBD device supports multiple communication modes, and generally each car only supports one kind of the communication protocol ,according to the protocol to pull up the unneeded pins by the pliers.(when the vehicle turns on,unplug and OBD cable and re-plug again,it will display the protocol)

T600

Introduction

the main function is to display the car dashboard information(e.g.speed,driving direction,local time,driving distance,driving time ),and keep the driver’s eyes always on road to avoid the dangerous of lowering down head to read the dashboard.

Main Functions&Features

1.Work for all the vehicles,easy installation,plug and play

2.TFT LCD multi color smart display

3.The language can be changed

4.Multi function display or simple function display can be switched freely

5.New functions: accelerating competitive mode ,Brake performance test

6.Rich Contents:driving speed,voltage,single driving distance,total driving distance,driving time,over speed alarm,freely switch between kilometers&miles.

Technical Parameters:

Environment temperature: -40c- + 80c

atmospheric pressure 86-106KPa

Relative Humidity: 10% -95%

environmental noise <= 60dB (A)

Alarm sound level: 》=30dB (A)

Working voltage: 9V ~ 16Vdc (12Vdc / 400mA)

Product size: 73*68*46(cm)

Product Weight: 50 g

Troubleshooting

1.The screen without any display,and no power

Start the car engine;check if the cable line is tight;or connect the USB to the computer to check

2. Inaccurate time

When the device search the satellite successfully(the default 8:00 will change to China local time), set it to your local time and save and exit.

3.Inaccurate Speed

When the product is power on,long press in the button to enter into the menu option,and right push once switch to setting,then short press in the button to the menu,and right push the button switch to the speed adjust option.(if the dashboard shows 100,and the device shows the 101,change the default value at 106%)

4.Over speed alarm

Default alarm is 150KM/H,please refer to the setting to change the value.

5.The device cannot auto power off

After vehicle turns off,the device still display the speed,switch the setting to Speed Offset,and adjust the value same as the device speed.(if the device shows 5KM/H after the vehicle turns off,then change the speed offset at 5KM/H)

6.Wrong operation lead to crashes

Do a factory set
