Specification :
1 Port Gigabit Ethernet
– Injector or Splitter
– 1 Shielded RJ-45 LAN
– 1 Shielded RJ-45
LAN+POE – 10/100/1000 data rates
• Size: 6 x 1.3 x .8 inches
(150 mm x 29mm x 22mm)
• 1000 ma max current ( not fused)
• Use with any Ethernet switch – PoE or non-PoE switches
• Standard power connector
- 2.1mm x 5.5mm
• LED status indicator
• Operating Temperature
– 0 to 65 deg C
• Mode B operation- pins 4-5 (+) - pins 7-8 (-)
• Ideal for IP Cameras, VOIP phone, WiFi Access Points
• Select the power supply you need 12 to 56 volts.
• Power is always on
- No auto-negotiation
- Powers 802.3af / 802.3at devices “passively”
