800L/H 5m DC 12V 24V Solar Brushless Motor Water Circulation Water Pump Submersibles Water Pumps

Description:

1. This DC pump uses advanced electronic components and high-quality wear-resistant shaft.

2. It is smooth operation, high efficiency, good performance, long service life.

3. Long working life, continuous power-on working time of more than 10,000 hours.

4. Low noise, safety and environmental protection.

5. Apply brushless DC motor, can work without spark.

6. It is widely used in industry, scientific research, aerospace industry.

Specifications:

Item name: Brushless water pump

Material: Engineering plastic

Voltage: 12V DC

Power: 19W

Max Flow Rate: 800 L/H(m3/h)

Max Water Lift: 5m

Working Environment Temperature: 1-60 ℃

Max Circulating Water Temperature: 100°C

Noise: < 40 db (water) under operation

Drive Mode: Electromagnetic

Conveying Medium: Hot water pump

Pump Shaft Position: Horizontal

Impeller Structure: Open impeller

Impeller Suction Method: one suction type

Cable Line: 500mm / 19.69in

Item Size: 77 * 65 * 42mm / 3.03 * 2.56 * 1.65in

Package Weight: 220g / 7.76ounces

Package Size: 80 * 70 * 50mm / 3.15 * 2.76 * 1.97in

Usage:

The water pump cable (red line is positive, do not take the wrong) received a suitable power supply (the battery can be a battery, it can be a power converter), and then a good water pipe, then pump into the water, can be used normally.

(Note: The DC brushless pump is a centrifugal pump, the pump water flow with the increase of the head decreases.No diving without self-priming function, prohibit no water .)

Note:

1. Do not take the wrong pump positive and negative.

2. Prohibit not through the power converter will be connected directly to the 220V power supply pump.

3. It is strictly prohibited for strong acidity, alkali and other damage to the pump medium.

4. The pump is suitable for medium temperature 1 ℃ -60 ℃.

5. It is normal for the pump to have noise when it is idling, and the noise is less than 35 db when working.

6. There might be little error of size for manual measurement.

7. The colors deviation might differ due to different monitor settings, please kindly understand.

Packing list

1 x Brushless Motor Water Pump
