Product Description Following is the price list of optional accessories and function.

Hard-wire charger                                  USD 3.5 (without shipping) Cigarette lighter charger                    USD 3 (without shipping)     Online system fee and phone app 1 years               USD 5
5 years               USD 15 New Mini Global GPS Tracker for everyone (including yourself, your wife, your kids, your pet, your gold stash and everything else!). With compact design, convenient SMS functions and the latest in GPS tracking technology, it is the one all-purpose tracker for everyone needing to track their valuable asset and loved ones.



Easy to use: All you need is a working SIM card to insert into the unit, charge the battery, and you are ready to go. With Quad-Band GSM connectivity, it works anywhere in the world. It even comes with a handy weatherproof bag to attach to your belt or backpack.



Tracks Everyone and Everything:

•      Outdoor sports and recreation: Hiking, biking, skiing, mountaineering, etc, whatever your sport is, take one with you and your loved ones will have peace of mind while knowing exactly where you are.

•      Surveillance: Secretly put it with a person, or his belonging, and you can monitoring where they are going. It comes with a magnetic back cover to attach itself to any steel object, consciously or "unconsciously"!

•      Children and Seniors Citizens: drop it in their pocket or backpack and you will never have to worry about them getting lost again. All you need to do is make a call to the Mini Global GPS Tracker and it will text back their exact location to you instantly!

•

Apart from these simple track-n-trace functions, it also has more advanced functions such as:

- SOS button: It sends "Help ME" and location of the tracker to all authorized numbers.

- Geo-fencing control - When the tracker moves in/out the preset scope, it will send an SMS alarm to the authorized phone number.

- GPRS: With a GPRS enabled SIM card, you can monitor realtime movement of the tracker with the supplied software on your computer.





TK102B  SPECIFICATION



DIM. 64*46*27mm

Weight: 50g Network: GSM/GPRS Band: 850/900/1800/1900Mhz  GSM/GPRS Module: CB900 GPS Module: SIRF3 chip GPS sensitivity: -159dBm GPS Accuracy: 5m GPS Start Time:  Cold status  45s                            Warm status  35s                            Hot status  1s Built in Memory: 1MB Applicable:  vehicle power 12 V  Backup battery Chargeable: changeable 3.7V 800mAh Li-ion battery Storage Temp: -40°C to +85°C Operation Tem.: -20°C to +65°C Humidity: 5%--95% non-condensing Altitude Limit: 18,000 meters (60,000 feet) max Velocity Limit: 515 meters/second (1000 knots) max Online tracking system: Web based online tracking platform: www.gpstrackerxy.com                                                                           (demo account: demo, password: 8888.) Iphone/Android application Trackerhome     Features and functions   1.Built in memeory 1MB(16,000 positions) and optional 2GB external SD card at most. 2.Powerful magnet+water proof,adsorbing in the hidden place of car. 3.Multiple tracking ways;Provide monitor software with the global mapfree, real-time track by your computer or PDA cell phone or googleearth. 4. Standby 80hours. 5. Small cubage;Dimension: 46*64*17mm (1.8*2.5*0.65inch) Weight: 40g Integration design(antenna and battery inside);easy to hide and take along with you 6. Support orientation without orientated server: it can find out Real-time longitude and latitude, time and speed. By using public map software and entering longitude and latitude manually, you can find out the real-time information of position. 7. Can support platform: When using platform, it can track targets in real time on electronic map, or inquire the target’s position by mobile phone. 8. If the target you are inquiring enters into underground parking lot or other GPS blind area, the tracker will inform you the last orientation. 9. Tracking function by timing and frequency 10. Authorized number added and deleted function 11. Support hidden alarm and monitor function 12. Geo-fence: Set up a geo-fence for the unit to restrict its movements within a district. The unit will send the message to the authorized numbers when it breaches the district. 13. Movement alert: you can set up barriers when the tracker is stopped. Once moved, it can give an alarm to the authorized number. 14. Over speed alarm: you can make the inspected target run according to fixed speed. It alarms when speed is exceeded. 15. Low battery alarm function  16. Shock sensor alarm (Built in) 17. Absolute street address by SMS Tracking solutions 1. SMS tracking on cellphone with a googlemap link to view current location on map  on cellphone screen.   2. Get absolute address by SMS 3. PC Installation software tracking.    4. Web server online tracking www.gpstrackerxy.com





Online tracking system





Android App



Iphone App

I




Package Contents
Mini Global GPS Tracker

Battery Charger
Power Adaptor
2 x Batteries
Battery Cover with Magnet
Plastic Holder Bag
English Manual
Hard-wire charger (Optional)
Cigarette lighter charger (Optional)
