New WiFi TC421 Time Programable RGB LED Controller Dimmer TC420 DC12V 24V 5Channel Total Output 20A WiFi Aquarium Lighting Timer

Summarization

There is an upper computer in the TC421 WiFi programmable time controller to make the load output change over time, the customer may customize schedule mode they want through the upper PC or APP client. Then through the USB port or wifi to download required schedule to the controller.The upper PC and Mobile phone APP to the client in addition to the function of editing schedule mode ,it also can be setup time for the controller because of synchronous clock function of upper host .If user want to see the schedule mode effect after editing , they can use fast sowing function of upper . Because there is no delete function of the upper host ,so the mode name display space will come into blank as long as you execute delete .This controller can control load of led changing effect no more than five channels .And it can be used in the occasion of the plant lights, light box advertising, the stage, home decoration, etc.

Working temperature: -20-60degree

Supply voltage: DC12~24V

Static power consumption: < 0.5W

Net weight: 200g

Gross weight: 360g

External dimension: 150MM*78.5MM*26MM

Packing size: 185MM*180MM*54.8MM

Output: 5 channels

Maximum output current: 20A

Packing List:

1. 1pcs TC421 WiFi programmable led time controller

2. 1pcs CD-ROM (Software, Software Instructions and User Manual inside)

3. 1pcs USB data Cable

4. 1pcs User Manual.
