T: temperature

H:humidity

for example :T and H with 4-20ma  means the product can measure temerature and humidty with 4-20ma output

Soil moisture sensor, soil temperature sensor, soil temperature and humidity sensor (voltage type (0-2V, 0.4-2V), current type (0-20mA,4-20mA), Type 485)

Equipped with 3 meters long

Soil moisture sensors are based on dielectric theory and have been independently developed using frequency-domain measurement techniques to accurately measure the volumetric moisture content of soil and other porous media. It can be integrated with systems such as greenhouse environmental monitoring, soil moisture collection, and automatic irrigation control to achieve long-term continuous dynamic monitoring of moisture.

Applicable to water-saving agricultural irrigation, greenhouse vegetables, flower gardening, grassland pasture, soil rapid measurement, plant cultivation, scientific experiments and other fields.

⊙Technical Parameters

□Measurement parameters:Soil volume moisture content

□ Measurement range: Temperature: -30--70°C Humidity: 0-100%

□ Probe length: 5.5cm

□ Probe diameter: 3mm

□ Probe material: stainless steel

□ Sealing material: epoxy resin

□ Measurement accuracy: ±3%

□ Temperature range: -30°C to 70°C

□ Operating voltage: 7 to 24V

□ Working current:

□ Measurement frequency: 100MHz

□Measurement area: centered on the center probe, 7cm in diameter and 7cm in height around the central probe

□ Cable length: 3 meters (standard)

Voltage type

.Supply voltage: 5V to 24V DC

.Output signal: 0 ~ 2V (customizable 0.4-2V)

Current type

.Supply voltage: 12V to 24V DC

.Output signal: 0 to 20mA (customizable4-20mA)

.Output load:

485 communication

 .Supply voltage: 5V to 24V DC

The soil moisture sensor communication protocol uses the standard modbus communication protocol
