The instrument flickers at a certain frequency.LEDnewlight source，in useThe instrumentObservation of objects rotating or moving at high speeds，By adjustingLEDFlash Frequency of Lamp，When it is close to or synchronized with the rotating or moving speed of the object under test，Although the object under test is moving at high speed，But it seems to be moving slowly or stationary.，It can be used to detect the rotating speed of the object or the surface quality or running condition of the high-speed moving object.。

The instrument is used.Of course.LEDAs a light source，Compared with the traditional xenon lamp，High brightness、Long life、Reliable triggerVarious advantages。Application of the instrumentDigital Frequency Synthesis Technology，Flicker Frequency Output More Precision、Stable、reliable。Stroboscopic output adjustment360Degree rotary dialAnd combination ratio gear switch，Flicker speed can be adjusted quickly or slowly by any left-right unlimited rotation.，Light and convenient operation of numerical increment and subtraction。The instrument is used.LCDAct asdisplay，ReadingMore than the previous generation of productsclear，Operating interface display information intuitively。This instrumentSmall, light and easy to carry、Easy to hold and read、Beautiful appearance。Its characteristic is that the accuracy of velocity measurement is relatively high.，Because of non-contact speed measurement，Easy to operate，It has the unique superiority of flash speed measurement。

Therefore, the instrument is especially suitable for motor.、Fan、pump、Speed Measurement of Gears，Quality Inspection of High Speed Production Line and Diagnosis of Product Vibration；Applicable to HVAC、printing、Papermaking、Spin、medicine、light industry、Machinery processing and other industries。

Two、 Main technical parameters

1、Actualrange: 200---50000Flash frequency/Minute

2、Accuracy of Velocity Measurement：0.001%。

3、illumination：750LUX

4、display: LCDDisplay。

5、Power Supply: 7.4V/1100mAlithium battery。

6、Power waste：Working≤0.2W，Continuous operation8hour，Standby time3Months。

7、Working environment temperature：-10°~55°

8、size: 152x61x55 （mm）。

9、weight: 184g（Containing batteries）。
