KKmoon 20000mW DIY Desktop Laser Engraver Printer Portable Engraving Carving Machine Mini Carver for Metal Wood |

KKmoon 20000mW DIY Desktop Laser Engraver Printer Portable Engraving Carving Machine Mini Carver for Metal Wood |

Features:
It is not a DIY kit. After strict quality inspection, the whole machine was tested and assembled at the factory, you just need to assemble the X-axis and Y-axis together, very easy to get started.
Support "neje scanner" app, intelligent collection and creation, photo scanning, intelligent algorithm automatic connection printing. Taking a .JPG or .PNG photo from camera or album, and send the photo to the windows software directly.
The machine in-built with a gyroscope protection device. When the machine is running, the built-in gyroscope will record the working position at the beginning. If there is an accidental touch or the machine is displaced, the machine will automatically stop working to prevent accidents.
Professional file processing algorithm, the software can restore your design 1:1 lossless to each pixel. A variety of image algorithms better present the image characteristics of your family or idol.
Getting the driver and software installed was real easy. Download and install directly from the link, the software will be automatically connected after opening the software.
Provide professionals with the ability to directly parse the works designed by Inkscape and CAD software, directly execute .nc files and .dxf files, and execute them accurately. You can do the complex edits in PS / Inkscape / CAD or similar and just burn with the included program.
Full-featured that directly execute .BMP, .JPG, .PNG files and "NEJE CLOUD" provides thousands of engraving materials and resources to download and keep updating.
Standard 405nm laser tube. 405nm laser is easily absorbed by the material, the engraving effect is very delicate, TTL control, temperature sensing, safer use, and greater engraving depth.
Compatible with a variety of power lasers, while supporting 4pin 405nm 3500mw, 445nm 4pin 7000mw, future support for larger laser power, TTL control and temperature sensing, can replace the power of the power supply equipment to achieve power expansion.
150 x 150mm engraving area (2000x2000px, 0.075mm dot pitch)
The laser focus is easy to adjust with your hands, and the focusing head is fixed with a rubber gasket.
Limit switch design, the machine can automatically reset.
The Windows version allows you to adjust laser power (burn depth and speed).
You can check your work after a pause, and starts back up where it left off.
Application: Grayscale Engraving, Photo Engraving, Wood Marking, Paper cutting
Engraving material: wood, gray paper card, non-transparent plastic, leather, paint pcba, etc.( flat, opaque and can be burned black)

Specifications:
Plug Type: EU / US (Optional)
Material: Acrylic+aluminum+stainless Steel
Main Color: Black
Input: 12V, 280mA (about 3500mw)
Output optical power: 600mw
PWM: 50KHz-20KHz / 3.3V-12V
Temperature Sensor: yes
Focus range: 0mm-50mm ( Recommend 0-10mm)
Max cutting thickness(Non Woven Fabric): 3mm(Light diameter:<0.15mm)
Minimum Focus Diameter:0.01mm ( Recommend Focus Range<10mm)
Image Format:.nc \ .dxf \ .bmp \ .jpg \ .png etc..
Image Size:2000 * 2000 pixels / 0.075mm point distance
Support System:WinXP / Win7 / Win8 / XP / Win10, Mac OS, android APP(neje scanner)
Machine Supply Voltage: 12V2A
Z-axis extension: yes
Sensor safety protection: yes
Engraving Area: 150 * 150mm
Item Size: 38 * 28 * 13cm / 14.96 * 11.02 * 5.12in
Item Weight: 1300g / 45.86oz
Package Weight: 1900g / 67.02oz
Package Size: 43 * 27 * 14.5cm / 16.93 * 10.63 * 5.71in

Package List:
1 * Engraving Machine
1 * Protective Glasses
1 * USB Cable
1 * Wrench
1 * Allen Wrench
1 * Whiteboard Marker
2 * Wood Block
2 * Cable Ties
2 * Power Adapter
5 * Nut
5 * Paper

Note:
1.Items can be carved including: mahogany, bamboo, paper cards, ivory, leather, flammable plastic, PCBA, etc. please take notice that the laser head is easily-consumed products.
2.It can not engrave metal, acrylic and any other retardant material. white material doesn't work well.
3.The product is only suitable for personal DIY, because of the speed of carving, it is not recommended for industrial use.
4.When the machine is working, it is recommended not to look directly at the laser head, and not to operate the laser head directly by hand.
5.Laser diode is a sensitive component, pay attention to prevent electrostatic damage (product includes electrostatic protection design, but there is a certain probability of damage).
